Downhill-oriented geometries for epic fun. It is the only one on the market to let you do what would be impossible with the others.
POWER UNIT

The XEF1.9 Race is equipped with the Brose S Mag motor, designed for the most active riders (torque 90 Nm,only 2,8Kg). In addition to power, the other plus features of the motor are quietness and smoothness of riding.

The 720 Wh battery is characterized by its long life even when under severe conditions.

Click here for more info.

SPECS
Specifications
Motor: Brose S-MAG 36 Volt, Max power: 250 Watt, Torque/Coppia: 90 Nm
Battery : Fantic Integra, Lithium Ion, 36 Volt, 720Wh
Display: Brose-All Round 4 multifunctional display & push-assistance selection unit
Frame: Aluminum, Sizes: S - M - L
Fork : RockShox ZEB e-bike - 29" 190mm
Shock: RockShox SuperDeluxe Coil Select+ T205x65
Chain rings: Sram 34t Steel Eagle
Crank arm: FSA CK-320/ISIS - 155mm
Rear derailleur: Sram NX Eagle 12V
Shift Levers: Sram NX E-click
Cassette: Sram SX Eagle 12V, 11-50
Chain: Sram NX Eagle 12V
Brake (front): Sram Code R 4 Piston disc brake
Brake (rear): Sram Code R 4 Piston disc brake
Disc (front): braking S3 Battfly, 220mm - 6Hole
Disc (rear): braking S3 Battfly, 203mm - 6Hole
Tires (front): Vittoria E-MAZZA 29"x 2.6
Tires (rear): Vittoria E-MARTELLO 27,5"x 2.8
Wheels : Mavic E-XM
Front hub : Sram 700
Rear hub : Sram 700
Handlebar: FSA GRID 800mm-35 RISE15
Stem: FSA GRID 50mm-35 RISE6°
Seatpost : SWITCH SW Ø 30.9 S-M(100mm), L(125mm)
Saddle: Sella Italia Novus Boost EVO
*FANTIC MOTOR reserves the right to modify technical caracteristics without prior notice.
